Main filter media for stainless steel pleated filter elements: Stainless steel sintered fiber web and stainless steel wire woven cloth. Stainless steel sintered fiber web is the product of Bekaert Fibre Technologies of Belgium.

Directions of Filter Elements Model: PF-D/L-R
D-Outside Diameter
L-Length
R-Filtration Rating

Advantages of stainless steel pleated filter elements:

High dirt holding capacity High reliable standard specifications Stainless steel pleated filter element has low pressure drop due to high porosity Pleated filter element has accurate filtration rating Easily cleanable by conventional chemical cleaning and with a long life-span Filtration area of pleated stainless steel filter element is increased by pleating

Available Filtration Rating (µm): 3, 5, 7, 10, 15, 20, 25, 30, 40, 60.

Sizes of Pleated Filter Elements: Any outline size available according to customer's requirement.

Technical Index of Stainless Steel Sintered Fiber Web:
